Same model may have multiple batches, images only for reference.
SRN5040TA-3R3M Real Image
Same model may have multiple batches, images only for reference.

SRN5040TA-3R3M

Part No SRN5040TA-3R3M
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Datasheet
SRN5040TA-3R3M Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SRN5040TA
Package Tape & Reel
Type Drum Core, Wirewound
Material - Core Ferrite
Inductance 3.3 µH
Tolerance ±20%
Current Rating (Amps) 3.5 A
Current - Saturation (Isat) 4.4A
Shielding Semi-Shielded
DC Resistance (DCR) 24mOhm
Q @ Freq 15 @ 100kHz
Frequency - Self Resonant 48MHz
Ratings AEC-Q200
Temperature Range - Operating -55°C ~ 125°C
Inductance Frequency - Test 100 kHz
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.195" L x 0.195" W (4.95mm x 4.95mm)
Height - Seated (Max) 0.161" (4.10mm)
Base Product Number SRN5040TA
Other Names SRN5040TA-3R3MTR,SRN5040TA-3R3MDKR,SRN5040TA-3R3MCT
Standard Package 1,500
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.4000
Win Source Part Number 1274292-SRN5040TA-3R3M
Ultra Librarian 3D Model Ultra Librarian SRN5040TA-3R3M CAD Model

Description

The SRN5040TA-3R3M is a semi-shielded fixed inductor from Bourns Inc. with an inductance of 3.3 µH.

  • Q Factor: 15 @ 100 kHz
  • Self-Resonant Frequency: 48 MHz
  • Tolerance: ±20%
  • DC Resistance: 24mOhm
  • Mounting: SMD (SMT)
  • Package: Nonstandard
  • Height: 0.161" (4.10mm)
  • Dimension: 0.195" L x 0.195" W (4.95mm x 4.95mm)
  • Core Material: Ferrite
  • Operating Temperature Range: -55°C ~ 125°C
  • AEC-Q200: Rated
