Same model may have multiple batches, images only for reference.
SRN5040TA-R60M Real Image
Same model may have multiple batches, images only for reference.

SRN5040TA-R60M

Part No SRN5040TA-R60M
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Datasheet
SRN5040TA-R60M Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SRN5040TA
Package Tape & Reel
Type Drum Core, Wirewound
Material - Core Ferrite
Inductance 600 nH
Tolerance ±20%
Current Rating (Amps) 8 A
Current - Saturation (Isat) 11A
Shielding Semi-Shielded
DC Resistance (DCR) 8mOhm
Q @ Freq 15 @ 100kHz
Frequency - Self Resonant 250MHz
Ratings AEC-Q200
Temperature Range - Operating -55°C ~ 125°C
Inductance Frequency - Test 100 kHz
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.195" L x 0.195" W (4.95mm x 4.95mm)
Height - Seated (Max) 0.161" (4.10mm)
Base Product Number SRN5040TA
Other Names SRN5040TA-R60MDKR,SRN5040TA-R60MCT,SRN5040TA-R60MTR
Standard Package 1,500
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.4000
Win Source Part Number 1274288-SRN5040TA-R60M
Ultra Librarian 3D Model Ultra Librarian SRN5040TA-R60M CAD Model

Description

The Bourns SRN5040TA-R60M is a fixed inductor that is surface-mounted and is available in tape and reel packaging.

  • Structure: Semi-shielded drum core wirewound
  • Inductance: 600nH
  • Tolerance: ±20%
  • DC Resistance: 8mOhm
  • Q @ Freq: 15 @ 100kHz
  • Frequency of Self-Resonance: 250MHz
  • Current Rating: 8A
  • AEC-Q200: Rated
  • Package/Case: Non-standard
  • Operating Temperature Range: -55°C to 125°C
