Same model may have multiple batches, images only for reference.
SRP1245C-8R2M Real Image
Same model may have multiple batches, images only for reference.

SRP1245C-8R2M

Part No SRP1245C-8R2M
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Datasheet
SRP1245C-8R2M Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SRP1245C
Package Tape & Reel
Material - Core Metal
Inductance 8.2 µH
Tolerance ±20%
Current Rating (Amps) 11.5 A
Current - Saturation (Isat) 20A
Shielding Shielded
DC Resistance (DCR) 21.5mOhm Max
Q @ Freq 20 @ 100kHz
Frequency - Self Resonant 13MHz
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 100 kHz
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.531" L x 0.496" W (13.50mm x 12.60mm)
Height - Seated (Max) 0.197" (5.00mm)
Other Names 118-SRP1245C-8R2MTR,118-SRP1245C-8R2MDKR,118-SRP1245C-8R2MCT
Standard Package 500
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.8000
Win Source Part Number 1274058-SRP1245C-8R2M
Ultra Librarian 3D Model Ultra Librarian SRP1245C-8R2M CAD Model

Description

The Bourns Inc. SRP1245C-8R2M is a fixed inductor with a metal core and a shielding feature.

  • Inductance: 8.2 μH
  • Tolerance: ±20%
  • Inductor Frequency Test: 100 kHz
  • Q @ Freq: 20 @ 100kHz
  • Package/Case: Nonstandard
  • Mounting: SMD (SMT)
  • Operating Temperature: -40°C to 125°C
  • Current Rating: 11.5 A
  • Saturation Current: 20A
