SRP3012TA-2R2M

Part No SRP3012TA-2R2M
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SRP3012TA
Package Tape & Reel
Type Drum Core, Wirewound
Material - Core Carbonyl Powder
Inductance 2.2 µH
Tolerance ±20%
Current Rating (Amps) 2.7 A
Current - Saturation (Isat) 3.4A
Shielding Shielded
DC Resistance (DCR) 115mOhm Max
Frequency - Self Resonant 45MHz
Ratings AEC-Q200
Temperature Range - Operating -40°C ~ 150°C
Inductance Frequency - Test 100 kHz
Mounting SMD (SMT)
Package / Case 2-SMD
Supplier Device Package 2-SMD
Dimension 0.138" L x 0.126" W (3.50mm x 3.20mm)
Height - Seated (Max) 0.047" (1.20mm)
Base Product Number SRP3012TA
Other Names SRP3012TA-2R2MTR,SRP3012TA-2R2MCT,SRP3012TA-2R2MDKR
Standard Package 4,000
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.4000
Win Source Part Number 1273975-SRP3012TA-2R2M
Ultra Librarian 3D Model Ultra Librarian SRP3012TA-2R2M CAD Model

Description

The SRP3012TA-2R2M is a fixed inductor manufactured by Bourns Inc.

  • Type: Drum Core, Wirewound
  • Rating: AEC-Q200 rated applications
  • Inductance: 2.2 μH
  • Current Rating: 2.7 A
  • Tolerance: ±20%
  • Mounting Type: Surface Mount
  • Packaging: Tape and Reel
