Same model may have multiple batches, images only for reference.

SRP3020TA-3R3M

Name: SRP3020TA-3R3M
Brand: Bourns Inc.
SKU: 1273948
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	SRP3020TA-3R3M
Manufacturer	Bourns Inc.
Catalog	Fixed Inductors
Datasheet	SRP3020TA-3R3M Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Inductors, Coils, Chokes>Fixed Inductors
Mfr	Bourns Inc.
Series	SRP3020TA
Package	Tape & Reel
Type	Drum Core, Wirewound
Material - Core	Carbonyl Powder
Inductance	3.3 µH
Tolerance	±20%
Current Rating (Amps)	3 A
Current - Saturation (Isat)	3.5A
Shielding	Shielded
DC Resistance (DCR)	145mOhm Max
Q @ Freq	10 @ 100kHz
Frequency - Self Resonant	40MHz
Ratings	AEC-Q200
Temperature Range - Operating	-40°C ~ 150°C
Inductance Frequency - Test	100 kHz
Mounting	SMD (SMT)
Package / Case	2-SMD
Supplier Device Package	2-SMD
Dimension	0.138" L x 0.126" W (3.50mm x 3.20mm)
Height - Seated (Max)	0.079" (2.00mm)
Base Product Number	SRP3020TA
Other Names	SRP3020TA-3R3MDKR,SRP3020TA-3R3MCT,SRP3020TA-3R3MTR
Standard Package	3,000
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8504.50.4000
Win Source Part Number	1273948-SRP3020TA-3R3M
Ultra Librarian 3D Model	Ultra Librarian SRP3020TA-3R3M CAD Model

Alternative Products

Description

The SRP3020TA-3R3M is a wirewound drum core inductor from Bourns Inc. that features a carbonyl powder core and is shielded to prevent electromagnetic interference.

Standard Package: 3,000
Mounting: SMD (SMT)
Inductance: 3.3 µH
Tolerance: ±20%
DC Resistance: 145 mOhm max
Current Rating: 3 A
Q @ Freq: 10 @ 100kHz
Frequency Self-Resonant: 40MHz
Temperature Range: -40°C to 150°C
AEC-Q200 Rated: Yes
Dimension: 0.138" L x 0.126" W (3.50mm x 3.20mm)
