Same model may have multiple batches, images only for reference.
SRR1260-5R6Y Real Image
Same model may have multiple batches, images only for reference.

SRR1260-5R6Y

Part No SRR1260-5R6Y
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Datasheet
SRR1260-5R6Y Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SRR1260
Package Tape & Reel
Type Drum Core, Wirewound
Material - Core Ferrite
Inductance 5.6 µH
Tolerance ±30%
Current Rating (Amps) 6.7 A
Current - Saturation (Isat) 6.9A
Shielding Shielded
DC Resistance (DCR) 16.2mOhm Max
Q @ Freq 19 @ 7.96MHz
Frequency - Self Resonant 33MHz
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 100 kHz
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.492" L x 0.492" W (12.50mm x 12.50mm)
Height - Seated (Max) 0.256" (6.50mm)
Base Product Number SRR1260
Other Names SRR1260-5R6YCT,SRR1260-5R6Y,SRR1260-5R6YTR,SRR1260-5R6YDKR
Standard Package 600
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.4000
Win Source Part Number 1273437-SRR1260-5R6Y
Ultra Librarian 3D Model Ultra Librarian SRR1260-5R6Y CAD Model

Description

The SRR1260-5R6Y is a shielded drum core inductor from Bourns Inc.

  • Inductance: 5.6 µH
  • Tolerance: ±30%
  • Core Material: Ferrite
  • Q @ Freq: 19 @ 7.96MHz
  • DC Resistance (DCR): 16.2mOhm Max
  • Current Rating (Amps): 6.7 A
  • Inductance Frequency for Test: 100 kHz
  • Package/Case: Nonstandard
  • Mounting: SMD (SMT)
  • Temperature Range: -40°C ~ 125°C
  • Dimension: 0.492" L x 0.492" W (12.50mm x 12.50mm)
  • Package: Tape and reel
  • Standard Package: 600
  • REACH: Unaffected
  • ECCN: EAR99
  • MSL Level: 1 (unlimited)
