SRR1280-390M Real Image
Same model may have multiple batches, images only for reference.

SRR1280-390M

Part No SRR1280-390M
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Datasheet
SRR1280-390M Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SRR1280
Package Tape & Reel (TR),Cut Tape (CT)
Type Drum Core, Wirewound
Material - Core Ferrite
Inductance 39 µH
Tolerance ±20%
Current Rating (Amps) 3.2 A
Current - Saturation (Isat) 3.1A
Shielding Shielded
DC Resistance (DCR) 70mOhm Max
Q @ Freq 24 @ 2.52MHz
Frequency - Self Resonant 8.5MHz
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 100 kHz
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.492" L x 0.492" W (12.50mm x 12.50mm)
Height - Seated (Max) 0.315" (8.00mm)
Base Product Number SRR1280
Other Names SRR1280-390MTR,-SRR1280-390MCT,-SRR1280-390M,SRR1280-390MCT,-SRR1280-390M,SRR1280-390M,SRR1280390M,-SRR1280-390MTR
Standard Package 400
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.4000
Win Source Part Number 1273393-SRR1280-390M
Ultra Librarian 3D Model Ultra Librarian SRR1280-390M CAD Model

Description

The SRR1280-390M is a shielded drum core wirewound fixed inductor from Bourns Inc. This inductor has an inductance of 39 µH and a tolerance of ±20%.

  • DC Resistance (DCR): 70mOhm Max
  • Current Rating: 3.2 A
  • Core Material: Ferrite
  • Q @ Freq: 24 @ 2.52MHz
  • Frequency - Self-Resonant: 8.5MHz
  • Height-Seated (Max): 0.315" (8.00mm)
  • Package/Case: Nonstandard
  • Temperature Range: -40°C to 125°C
