CDSOD323-T05LC Real Image CDSOD323-T05LC real image CDSOD323-T05LC real image15255 CDSOD323-T05LC Real Image1 CDSOD323-T05LC Real Image2
Same model may have multiple batches, images only for reference.
CDSOD323-T05LC Real Image CDSOD323-T05LC real image CDSOD323-T05LC real image15255 CDSOD323-T05LC Real Image1 CDSOD323-T05LC Real Image2
CDSOD323-T05LC Real Image CDSOD323-T05LC real image CDSOD323-T05LC real image15255 CDSOD323-T05LC Real Image1 CDSOD323-T05LC Real Image2
Same model may have multiple batches, images only for reference.

CDSOD323-T05LC

Part No CDSOD323-T05LC
Manufacturer Bourns Inc.
Catalog TVS - Diodes
Description TVS DIODE 5VWM 18.3VC SOD323
Datasheet
CDSOD323-T05LC Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Bourns Inc.
Packaging Reel - TR
Status Active
Type Zener
Bidirectional Channels 1
STAND-OFF Voltage (Vwm) 5V
Minimum Breakdown Voltage 6V
Max Clamping Voltage 18.3V (Typ)
Peak Pulse Current(Ippm) 15A (8/20μs)
Power Dissipation - Pd 250W
Applications HDMI, USB OTG
Capacitance @ Frequency 1pF @ 1MHz
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package SOD-323
Win Source Part Number 1028984-CDSOD323-T05LC
Popularity Medium
Supply and Demand Status Limited
Application Field Used in Communications & Networking
Ultra Librarian 3D Model Ultra Librarian CDSOD323-T05LC CAD Model

Description

The Bourns Inc. CDSOD323-T05LC is a high-quality zener diode designed for use in HDMI and USB OTG applications.

  • Channel: Bidirectional
  • Capacitance: 1pF @ 1MHz
  • Stand-off Voltage: 5V
  • Minimum Breakdown Voltage: 6V
  • Maximum Clamping Voltage: 18.3V (Typ)
  • Peak Pulse Current: 15A (8/20μs)
  • Power Dissipation: 250W
  • Package: SMD (SMT)
  • Reliable and efficient solution: Circuit protection applications
  • Popularity: Medium
  • Supply and Demand Status: Limited
  • Commonly Used: Communications and networking applications
