Same model may have multiple batches, images only for reference.
CRL1206-JW-R560ELF Bourns Inc. – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

CRL1206-JW-R560ELF

Part No CRL1206-JW-R560ELF
Manufacturer Bourns Inc.
Catalog Chip Resistor - Surface Mount
Description RES 0.56 OHM 5% 1/2W 1206
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Resistance 560 mOhms
Tolerance ±5%
Power (Watts) 0.5W, 1/2W
Composition Thick Film
Temperature Coefficient ±200ppm/°C
Temperature Range - Operating -55°C ~ 155°C
Case / Package 1206 (3216 Metric)
Supplier Device Package 1206
Size / Dimension 0.126" L x 0.063" W (3.20mm x 1.60mm)
Height - Seated (Max) 0.028" (0.70mm)
Number of Terminations 2
Package Tape & Reel
Supply and Demand Status Normal
Win Source Part Number 1586202-CRL1206-JW-R560ELF
Ultra Librarian 3D Model Ultra Librarian CRL1206-JW-R560ELF CAD Model

Description

N
