Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Circuit Protection - Transient Voltage Suppressors (TVS) - TVS Diodes
Mfr Bourns Inc.
Series SMCJ
Package Tape & Reel
Product Status Active
Type Zener
Bidirectional Channels 1
Voltage - Reverse Standoff (Typ) 440V
Voltage - Breakdown (Min) 492V
Voltage - Clamping (Max) @ Ipp 713V
Current - Peak Pulse (10/1000µs) 2.1A
Power - Peak Pulse 1500W (1.5kW)
Power Line Protection No
Applications General Purpose
Temperature Range - Operating -55°C ~ 150°C (TJ)
Mounting Type Surface Mount
Package / Case DO-214AB, SMC
Supplier Device Package DO-214AB (SMC)
Base Product Number SMCJ44
Standard Package 3,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Affected
ECCN EAR99
HTSUS 8541.10.0080
California Prop 65 Warning Information
Win Source Part Number 668932-SMCJ440CA
Ultra Librarian 3D Model Ultra Librarian SMCJ440CA CAD Model

Description

The SMCJ440CA is a Zener type TVS diode designed for general-purpose circuit protection.

  • Type: Zener TVS Diode
  • Series: SMCJ
  • Package: DO-214AB (SMC)
  • Voltage Reverse Standoff: 440V
  • Voltage Breakdown: 492V
  • Clamping Voltage: 713V @ peak pulse current (Ipp)
  • Peak Pulse Power: 1500W (1.5kW)
  • Mounting: Surface mountable
  • Packaging: Tape and Reel
  • Standard Package: 3,000 pcs
  • Operating Temperature: -55°C to 150°C (TJ)
  • Manufacturer: Bourns Inc.
  • Status: Active
  • Compliance: California Prop 65
