HCPL-3120 Real Image HCPL-3120 Real Image
Same model may have multiple batches, images only for reference.
HCPL-3120 Real Image HCPL-3120 Real Image
HCPL-3120 Real Image HCPL-3120 Real Image
Same model may have multiple batches, images only for reference.

HCPL-3120

Part No HCPL-3120
Manufacturer Broadcom Limited
Catalog Isolators - Gate Drivers
Description OPTOISO 3.75KV GATE DRVR 8DIP GW
Datasheet
HCPL-3120 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Broadcom Limited
Packaging Reel - TR
Status Active
Technology Optical Coupling
Number of Channels 1
Isolation Voltage 3750Vrms
Common Mode Transient Immunity (Min) 25kV/μs
Propagation Delay tpLH / tpHL (Max) 500ns, 500ns
Pulse Width Distortion (Max) 300ns
Rise and Fall Time 100ns, 100ns
Current - Output High, Low 2A, 2A
Current - Peak Output 2.5A
Forward Voltage 1.5V
Continuous forward current- Max 25mA
Supply Voltage - Operating 15 V to 30 V
Temperature Range - Operating -40°C to 100°C
Mounting SMD (SMT)
Case / Package 8-DIP Gull Wing
Approvals CSA, UR
Win Source Part Number 067906-hcpl-3120
Popularity Medium
Supply and Demand Status Balance
Application Field Used in Industrial, Motor Drive & Control, Industrial
Quantity per package 50
Ultra Librarian 3D Model Ultra Librarian HCPL-3120 CAD Model

Description

The Broadcom Limited 067906-hcpl-3120 is an optical coupling technology isolator.

  • Channels: 1
  • Case/Package: 8-DIP Gull Wing
  • Current Output High: 2A
  • Current Output Low: 2A
  • Forward Voltage: 1.5V
  • Common Mode Transient Immunity (min): 25kV/μs
  • Propagation Delay tpLH (max): 500ns
  • Propagation Delay tpHL (max): 500ns
  • Isolation Voltage: 3750Vrms
  • Current Peak Output: 2.5A
  • Pulse Width Distortion (max): 300ns
  • Rise Time: 100ns
  • Fall Time: 100ns
  • Approvals: CSA and UR
  • Temperature Range: -40°C to 100°C
  • Packaging: Reel - TR
  • Applications: Industrial, motor drive & control, and industrial applications
