HCPL-M601-500E Real Image HCPL-M601-500E Real Image
Same model may have multiple batches, images only for reference.
HCPL-M601-500E Real Image HCPL-M601-500E Real Image
HCPL-M601-500E Real Image HCPL-M601-500E Real Image
Same model may have multiple batches, images only for reference.

HCPL-M601-500E

Part No HCPL-M601-500E
Manufacturer Broadcom Limited
Catalog Optoisolators - Logic Output
Description OPTOISO 3.75KV OPN COLLECTOR 5SO
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Broadcom Limited
Packaging Reel - TR
Status Active
Number of Channels 1
Inputs - Side 1/Side 2 1/0
Isolation Voltage 3750Vrms
Common Mode Transient Immunity (Min) 5kV/μs
Input Type DC
Output Type Open Collector, Schottky Clamped
Channel Output Current 50mA
Data Rate 10MBd
Propagation Delay tpLH / tpHL (Max) 75ns, 75ns
Rise and Fall Time 24ns, 10ns
Forward Voltage 1.5V
Continuous forward current- Max 20mA
Supply Voltage - Operating 4.5 V to 5.5 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 5-SO
Win Source Part Number 016892-HCPL-M601-500E
Popularity Medium
Supply and Demand Status Sufficient
Quantity per package 1,500
Ultra Librarian 3D Model Ultra Librarian HCPL-M601-500E CAD Model

Description

The Broadcom Limited 016892-HCPL-M601-500E is an SMD (SMT) mounted optocoupler with an open collector, Schottky clamped output type.

  • Mounting Type: SMD (SMT)
  • Output Type: Open Collector, Schottky Clamped
  • Data Rate: 10MBd
  • Forward Voltage: 1.5V
  • Input Type: DC
  • Channels: 1
  • Common Mode Transient Immunity: 5kV/μs
  • Propagation Delay tpLH (Max): 75ns
  • Propagation Delay tpHL (Max): 75ns
  • Isolation Voltage: 3750Vrms
  • Channel Output Current: 50mA
  • Continuous Forward Current: 20mA
  • Package: 5-SO
  • Operating Temperature: -40°C to 85°C
  • Operating Supply Voltage: 4.5 V to 5.5 V
  • Rise Time: 24ns
  • Fall Time: 10ns
  • Quantity per Reel: 1,500
