HEDL-5500#E06

Part No HEDL-5500#E06
Manufacturer Broadcom Limited
Catalog Encoders
Description ROTARY ENCODER OPTICAL 200PPR
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Sensors, Transducers - Encoders - Industrial
Mfr Broadcom Limited
Series HEDL
Package Bulk
Product Status Active
Encoder Type Optical
Output Type Quadrature (Incremental)
Pulses per Revolution 200
Voltage - Supply 5V
Actuator Type 1/4" Open Center
Detent No
Built in Switch No
Mounting Type Chassis Mount, Motors
Orientation Vertical
Termination Style Cable with Connector
Base Product Number HEDL-5500
Standard Package 20 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8543.70.4500
Win Source Part Number 920128-HEDL-5500#E06
Ultra Librarian 3D Model Ultra Librarian HEDL-5500#E06 CAD Model

Description

The HEDL-5500#E06 is an industrial encoder sensor produced by Broadcom Limited.

  • Orientation: vertical
  • Termination Style: cable and connector
  • Supply Voltage: 5V
  • Output Type: quadrature (incremental)
  • Actuator Type: 1/4" open center
  • Built-in Switch: no
  • Encoder Type: optical
  • Pulses per Revolution: 200
  • Mounting: chassis mount and motor applications
  • Package: bulk
  • Standard Package: 20 pieces
  • Series: HEDL
  • Status: active product
