HSMP-3814-TR1G Real Image HSMP-3814-TR1G real image4624 HSMP-3814-TR1G Real Image1 HSMP-3814-TR1G Real Image2
Same model may have multiple batches, images only for reference.
HSMP-3814-TR1G Real Image HSMP-3814-TR1G real image4624 HSMP-3814-TR1G Real Image1 HSMP-3814-TR1G Real Image2
HSMP-3814-TR1G Real Image HSMP-3814-TR1G real image4624 HSMP-3814-TR1G Real Image1 HSMP-3814-TR1G Real Image2
Same model may have multiple batches, images only for reference.

HSMP-3814-TR1G

Part No HSMP-3814-TR1G
Manufacturer Broadcom Limited
Catalog RF Diodes
Description DIODE PIN ATTENUATOR 100V SOT-23
Datasheet
HSMP-3814-TR1G Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Broadcom Limited
Packaging Reel - TR
Status Active
Diode Type PIN - 1 Pair Common Cathode
Voltage - Peak Reverse (Max) 100V
Current - Max 1A
Capacitance @ Vr, F 0.35pF @ 50V, 1MHz
Resistance @ If, F 3 Ohm @ 100mA, 100MHz
Temperature Range - Operating 150°C (TJ)
Case / Package SOT-23-3
Win Source Part Number 017031-HSMP-3814-TR1G
Family Name HSMP-3814
Introduction Date April 01, 2004
ECCN EAR99
Country of Origin Malaysia, Thailand
Halogen Free Compliant
Estimated EOL Date Obsolete
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian HSMP-3814-TR1G CAD Model

Description

The Broadcom Limited HSMP-3814 PIN diode is a high-quality optoelectronic component suitable for various applications. The diode comes in reel packaging with TR format and has a maximum current of 1A.

  • Diode Type: PIN-1 pair common cathode
  • Capacitance: 0.35pF at 50V and 1MHz
  • Voltage Peak Reverse: 100V
  • Resistance: 3 Ohm at 100mA and 100MHz
  • Status: Active
  • Family: HSMP-3814
  • Popularity: High
  • Supply and Demand: Balance
  • Compliance: Halogen-free regulations
  • Origin: Malaysia and Thailand
  • ECCN: EAR99
  • Status: Obsolete, with alternative parts available
  • Packaging: SOT-23-3
