HSMS-2828-TR1G Broadcom Limited HSMS-2828-TR1G label picture
Same model may have multiple batches, images only for reference.
HSMS-2828-TR1G Broadcom Limited HSMS-2828-TR1G label picture
HSMS-2828-TR1G Broadcom Limited HSMS-2828-TR1G label picture
Same model may have multiple batches, images only for reference.

HSMS-2828-TR1G

Part No HSMS-2828-TR1G
Manufacturer Broadcom Limited
Catalog RF Diodes
Description DIODE SCHOTTKY RF QD 15V SOT-143
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Broadcom Limited
Packaging Reel - TR
Status Active
Diode Type Schottky - 1 Bridge
Voltage - Peak Reverse (Max) 15V
Current - Max 1A
Capacitance @ Vr, F 1pF @ 0V, 1MHz
Resistance @ If, F 12 Ohm @ 5mA, 1MHz
Temperature Range - Operating 150°C (TJ)
Case / Package SOT-143-4
Win Source Part Number 1044090-HSMS-2828-TR1G
Popularity Medium
Supply and Demand Status Balance
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian HSMS-2828-TR1G CAD Model

Description

The Broadcom Limited HSMS-2828-TR1G is a Schottky diode with a maximum peak reverse voltage of 15V. Bold the product name (e.g., BAV99S,135 → HSMS-2828-TR1G) and manufacturer (e.g., Nexperia USA Inc. → Broadcom Limited).

  • Maximum Peak Reverse Voltage: 15V
  • Current Rating: 1A
  • Capacitance: 1pF @ 0V, 1MHz
  • Resistance @ If, F: 12 Ohm @ 5mA, 1MHz
  • Package: Reel-TR
  • Quantity per Package: 3k pcs
  • Operating Temperature Range: 150°C (TJ)
