MGA-86563-TR1G Broadcom Limited MGA-86563-TR1G real image MGA-86563-TR1G label picture
Same model may have multiple batches, images only for reference.
MGA-86563-TR1G Broadcom Limited MGA-86563-TR1G real image MGA-86563-TR1G label picture
MGA-86563-TR1G Broadcom Limited MGA-86563-TR1G real image MGA-86563-TR1G label picture
Same model may have multiple batches, images only for reference.

MGA-86563-TR1G

Part No MGA-86563-TR1G
Manufacturer Broadcom Limited
Catalog RF Amplifiers
Description AMP RFIC LNA GAAS 5V SOT-363
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer Broadcom Limited
Packaging Reel - TR
Status Active
Frequency 500MHz to 6GHz
P1dB 4.1dB (2.6mW)
Gain 22.7dB
Noise Figure 1.6dB
RF Type GPS, ISM, MMDS, PCS, TVRO
Supply Voltage - Operating 4.5 V to 7 V
Operating Supply Current 14mA
Test Frequency 2GHz
Case / Package SOT-363, SC70
Win Source Part Number 023219-MGA-86563-TR1G
Family Name MGA-86563
Introduction Date April 01, 2004
ECCN EAR99
Country of Origin Malaysia
Estimated EOL Date Obsolete
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian MGA-86563-TR1G CAD Model

Description

The Broadcom Limited MGA-86563-TR1G is a RF amplifier designed for GPS, ISM, MMDS, PCS, and TVRO.

  • Gain: 22.7dB
  • Noise Figure: 1.6dB
  • P1dB: 4.1dB (2.6mW)
  • Test Frequency: 2GHz
  • Package: SOT-363, SC70
  • Operating Supply Current: 14mA
  • RF Type: GPS, ISM, MMDS, PCS, TVRO
  • Popularity: High
  • Status: Active
  • Supply and Demand: Sufficient
  • Manufacturer: Broadcom Limited
