VMMK-2503-TR1G Broadcom Limited VMMK-2503-TR1G real image VMMK-2503-TR1G label picture
Same model may have multiple batches, images only for reference.
VMMK-2503-TR1G Broadcom Limited VMMK-2503-TR1G real image VMMK-2503-TR1G label picture
VMMK-2503-TR1G Broadcom Limited VMMK-2503-TR1G real image VMMK-2503-TR1G label picture
Same model may have multiple batches, images only for reference.

VMMK-2503-TR1G

Part No VMMK-2503-TR1G
Manufacturer Broadcom Limited
Catalog RF Amplifiers
Description 1 to 12 GHz GaAs Wideband Amplifier in Wafer Level Package | IC RF AMP GP 1GHZ-12GHZ 0402
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer Broadcom Limited
Packaging Reel
Status Obsolete
Frequency 1GHz ~ 12GHz
P1dB 17dBm
Gain 14dB
Noise Figure 3.3dB
RF Type General Purpose
Supply Voltage (V) 5V
Supply Current 65mA
Test Frequency 6GHz
Manufacturer Package 0402 (1005 Metric)
Supplier Device Package 0402
Manufacturer Pack Quantity 1
MSL Level 2 (1 Year)
Win Source Part Number 757954-VMMK-2503-TR1G
Family Name VMMK-2503
Introduction Date December 01, 2008
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date Obsolete
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian VMMK-2503-TR1G CAD Model

Description

The Broadcom Limited VMMK-2503 is a general-purpose RF amplifier with a frequency range of 1GHz to 12GHz. It has a gain of 14dB and a noise figure of 3.3dB. The P1dB is 17dBm, and the supply current is 65mA. This amplifier is packaged in a 0402 package and is obsolete. The VMMK-2503 is compliant with halogen-free regulations and has a balance of supply and demand. The estimated EOL date is obsolete. This amplifier is commonly used and has a high popularity of 47%. The VMMK-2503 has an MSL level of 2 and a supply voltage of 5V.

  • Component Type: RF Amplifier
  • Frequency Range: 1GHz to 12GHz
  • Gain: 14dB
  • Noise Figure: 3.3dB
  • P1dB: 17dBm
  • Supply Current: 65mA
  • Package: 0402
  • Status: Obsolete
  • Halogen-Free: Yes
  • Estimated EOL Date: Obsolete
  • Popularity: 47%
  • MSL Level: 2
  • Supply Voltage: 5V
