PS2701-1-F3-A CEL PS2701-1-F3-A Real Image PS2701-1-F3-A real image
Same model may have multiple batches, images only for reference.
PS2701-1-F3-A CEL PS2701-1-F3-A Real Image PS2701-1-F3-A real image
PS2701-1-F3-A CEL PS2701-1-F3-A Real Image PS2701-1-F3-A real image
Same model may have multiple batches, images only for reference.

PS2701-1-F3-A

Part No PS2701-1-F3-A
Manufacturer CEL
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISOLATOR 3.75KV TRANS 4SMD
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer CEL
Packaging Reel - TR
Status Active
Number of Channels 1
Isolation Voltage 3750Vrms
Minimum DC Current Transfer Ratio 50% @ 5mA
Maximum DC Current Transfer Ratio 300% @ 5mA
Rise and Fall Time 3μs, 5μs
Input Type DC
Output Type Transistor
Maximum Output Voltage 40V
Channel Output Current 80mA
Forward Voltage 1.1V
Continuous forward current- Max 50mA
Vce Saturation (Max) 300mV
Temperature Range - Operating -55°C to 100°C
Mounting SMD (SMT)
Case / Package 4-SMD
Win Source Part Number 026882-PS2701-1-F3-A
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name PS2701-1
Introduction Date December 12, 2000
ECCN EAR99
Halogen Free Not Compliant
Estimated EOL Date 2023
Ultra Librarian 3D Model Ultra Librarian PS2701-1-F3-A CAD Model

Description

The PS2701-1-F3-A from CEL is a transistor output type optoisolator.

  • Output Type: Transistor
  • Forward Voltage: 1.1V
  • Input: DC
  • Channels: 1
  • Package: 4-SMD
  • Maximum Output Voltage: 40V
  • Channel Output Current: 80mA
  • Minimum DC Current Transfer Ratio: 50% @ 5mA
  • Maximum DC Current Transfer Ratio: 300% @ 5mA
  • Application: Isolator
  • Isolation Voltage: 3750Vrms
  • Operating Temperature: -55°C to 100°C
