PS2802-4-F3-A Real Image PS2802-4-F3-A Real Image
Same model may have multiple batches, images only for reference.
PS2802-4-F3-A Real Image PS2802-4-F3-A Real Image
PS2802-4-F3-A Real Image PS2802-4-F3-A Real Image
Same model may have multiple batches, images only for reference.

PS2802-4-F3-A

Part No PS2802-4-F3-A
Manufacturer CEL
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISOLTR 2.5KV 4CH DARL 16SOIC
Datasheet
PS2802-4-F3-A Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer CEL
Packaging Reel - TR
Status Active
Number of Channels 4
Isolation Voltage 2500Vrms
Minimum DC Current Transfer Ratio 200% @ 1mA
Rise and Fall Time 200μs, 200μs
Input Type DC
Output Type Darlington
Maximum Output Voltage 40V
Channel Output Current 100mA
Forward Voltage 1.1V
Continuous forward current- Max 50mA
Vce Saturation (Max) 1V
Temperature Range - Operating -55°C to 100°C
Mounting SMD (SMT)
Case / Package 16-SSOP
Win Source Part Number 127025-PS2802-4-F3-A
Family Name PS2802-4
Introduction Date August 05, 2009
ECCN EAR99
Estimated EOL Date 2023
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian PS2802-4-F3-A CAD Model

Description

The PS2802-4-F3-A is a quad-channel optocoupler from the PS2802-4 series manufactured by CEL.

  • Product Series: PS2802-4
  • Manufacturer: CEL
  • Channel Count: Quad-channel
  • Output Type: Darlington
  • Input Type: DC
  • Forward Voltage: 1.1V
  • Mounting Type: Surface-mounted
  • Package: 16-SSOP
  • Isolation Voltage: 2500Vrms
  • Minimum DC Current Transfer Ratio: 200% @ 1mA
  • Temperature Range: -55°C to 100°C
  • Vce Saturation: 1V
  • Switching Turn-On and Turn-Off Time: Not specified
  • Rise and Fall Time: 200μs
  • Maximum Output Voltage: 40V
  • Channel Output Current: 100mA
  • ECCN: EAR99
