BAT54APT

Part No BAT54APT
Manufacturer Chenmko
Catalog END - OF - LIFE
Description SCHOTTKY DIODE VOLTAGE 30 Volts CURRENT 0.2 Ampere
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Chenmko
Win Source Part Number 1151541-BAT54APT
Manufacturer Homepage www.chenmko.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian BAT54APT CAD Model

Description

The BAT54APT is a Schottky barrier diode manufactured by Chenmko. This diode is designed for high-speed switching and low forward voltage drop in a variety of electronic applications. It is commonly used for rectification, clamping, and protection circuits. The “BAT54” designation indicates a specific series of Schottky diodes known for their fast switching characteristics.

Applications

  • High-speed switching circuits.
  • Reverse polarity protection.
  • Clamping circuits.
  • Voltage rectification in low-voltage applications.
  • DC-DC converters.

Features

  • Low forward voltage drop.
  • Fast switching speed.
  • Small surface mount package (SOT-23).
  • High surge current capability.
  • Lead-free finish, RoHS compliant.

Benefits

  • Improved efficiency in switching circuits due to low forward voltage drop.
  • Protection of sensitive components from reverse voltage.
  • Fast response time in clamping applications.
  • Space-saving design due to small package size.
  • Complies with environmental regulations.

Additional Details

The BAT54APT is a crucial component for enhancing the performance and protection of electronic circuits. Its low forward voltage drop minimizes power loss, making it suitable for energy-efficient designs. The fast switching speed allows for high-frequency operation, making it ideal for use in high-speed switching circuits and DC-DC converters. The SOT-23 package enables high-density board assembly, making it a popular choice for portable devices and other space-constrained applications. The diode's high surge current capability ensures that it can withstand transient voltage events without damage. The BAT54 series from Chenmko is widely recognized for its reliability and performance, making the BAT54APT a popular choice for a variety of electronic applications. Its lead-free finish and RoHS compliance ensure that it meets current environmental standards. Chenmko's commitment to quality ensures that the BAT54APT provides exceptional value for engineers and designers.
