The 0402HPH-68NXGLW is a high-performance, high-Q chip inductor manufactured by Coilcraft. It is designed for use in high-frequency applications where low losses and tight tolerances are critical. The inductor's small size and robust construction make it suitable for a wide range of wireless and RF applications.

Applications

• RF Filters
• Impedance Matching Networks
• Wireless Communication Circuits
• Low Noise Amplifiers (LNAs)
• Oscillators

Features

• High Q-Factor
• Tight Inductance Tolerance
• Small 0402 Package Size
• High Self-Resonant Frequency (SRF)
• RoHS Compliant

Benefits

• Improved Signal Integrity: The high Q-factor minimizes insertion loss and maximizes signal integrity in high-frequency circuits.
• Precise Circuit Performance: Tight inductance tolerance ensures accurate and predictable circuit behavior.
• Compact Design: The small 0402 package allows for high-density board layouts and miniaturization of electronic devices.
• Enhanced High-Frequency Performance: The high SRF enables the inductor to operate effectively at high frequencies without significant performance degradation.
• Environmentally Friendly: RoHS compliance ensures the product meets environmental regulations and is free from hazardous substances.

Additional Details

The 0402HPH-68NXGLW features an inductance value of 68 nH. The 0402 package measures 0.04 inches by 0.02 inches (1.0 mm x 0.5 mm), making it suitable for space-constrained applications. The wirewound construction provides a high Q-factor, which is essential for minimizing losses in RF circuits. The inductor is designed to maintain its performance characteristics over a wide temperature range. It is commonly used in matching networks, RF filters, and other high-frequency applications where precise inductance and low losses are critical. Detailed specifications, including the Q-factor versus frequency, SRF, DC resistance (DCR), and current handling capability, are available in the Coilcraft datasheet. The inductor is designed for automated assembly processes, facilitating high-volume production. It is crucial to follow the manufacturer's recommendations for soldering and handling to ensure reliable performance and avoid damage to the component. The high SRF allows for the use of this inductor in applications operating at several GHz.
