XAL1510-223MED

Name: XAL1510-223MED
Brand: Coilcraft
SKU: 698695
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	XAL1510-223MED
Manufacturer	Coilcraft
Catalog	Fixed Inductors
Description	POWER INDUCTOR, SHIELDED, 20% TO
Datasheet	XAL1510-223MED Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Inductors, Coils, Chokes - Fixed Inductors
Mfr	COILCRAFT
Series	XAL1510
Package	Strip
Product Status	Active
Type	Molded
Material - Core	Metal Composite
Inductance	22 µH
Tolerance	±20%
Current Rating (Amps)	14 A
Current - Saturation (Isat)	18.7A
Shielding	Shielded
DC Resistance (DCR)	16mOhm Max
Frequency - Self Resonant	6.3MHz
Ratings	AEC-Q200
Temperature Range - Operating	-40°C ~ 165°C
Inductance Frequency - Test	1 MHz
Mounting Type	Surface Mount
Package / Case	Nonstandard
Size / Dimension	0.638" L x 0.598" W (16.20mm x 15.20mm)
Height - Seated (Max)	0.394" (10.00mm)
Standard Package	1 pcs
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
Win Source Part Number	698695-XAL1510-223MED
Ultra Librarian 3D Model	Ultra Librarian XAL1510-223MED CAD Model

Alternative Products

Description

The XAL1510 series is a molded inductor designed for various electronic applications.

Size: 0.638" L x 0.598" W (16.20mm x 15.20mm)
Height: 0.394" (10.00mm)
Inductance: 22 µH
Tolerance: ±20%
Shielding: Shielded
Core Material: Metal Composite
DC Resistance (DCR): 16mOhm Max
Current Rating: 14 A
Operating Temperature Range: -40°C to 165°C
Mounting: Surface Mount
AEC-Q200 Rated: Yes
Suitable for Applications: Power supplies, automotive electronics, and industrial equipment
