CPDQR5V0U-HF Real Image CPDQR5V0U-HF real image15259
Same model may have multiple batches, images only for reference.
CPDQR5V0U-HF Real Image CPDQR5V0U-HF real image15259
CPDQR5V0U-HF Real Image CPDQR5V0U-HF real image15259
Same model may have multiple batches, images only for reference.

CPDQR5V0U-HF

Part No CPDQR5V0U-HF
Manufacturer Comchip Technology
Catalog TVS - Diodes
Description TVS DIODE 5VWM 12.5VC 0402
Datasheet
CPDQR5V0U-HF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Comchip Technology
Packaging Reel - TR
Status Active
Type Zener
Unidirectional Channels 1
STAND-OFF Voltage (Vwm) 5V
Minimum Breakdown Voltage 6V
Max Clamping Voltage 12.5V
Peak Pulse Current(Ippm) 16A (8/20μs)
Power Dissipation - Pd 200W
Applications General Purpose
Capacitance @ Frequency 90pF @ 1MHz
Mounting SMD (SMT)
Case / Package 0402/SOD-923F
Win Source Part Number 1030083-CPDQR5V0U-HF
Popularity Medium
Supply and Demand Status Sufficient
Quantity per package 5k pcs
Ultra Librarian 3D Model Ultra Librarian CPDQR5V0U-HF CAD Model

Description

The 1030083-CPDQR5V0U-HF from Comchip Technology is a high-quality zener diode designed for general-purpose applications.

  • Channels: unidirectional
  • STAND-OFF Voltage: 5V
  • Minimum Breakdown Voltage: 6V
  • Maximum Clamping Voltage: 12.5V
  • Peak Pulse Current: 16A (8/20μs)
  • Power Dissipation: 200W
  • Package: 0402/SOD-923F
  • Market Popularity: popular
  • Supply and Demand Status: sufficient
  • Package Quantity: 5k pcs
