C3M0120100K

Name: C3M0120100K
Brand: Cree/Wolfspeed
SKU: 847301
Availability: InStock
Rating: 4.93 (5 reviews)

Get a Quote

Part No	C3M0120100K
Manufacturer	Cree/Wolfspeed
Catalog	Transistors - FETs, MOSFETs - RF
Description	SICFET N-CH 1000V 22A TO247-4L
Datasheet	C3M0120100K Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Discrete Semiconductor Products - Transistors - FETs, MOSFETs - Single FETs, MOSFETs
Mfr	Cree/Wolfspeed
Series	C3M™
Package	Tube
Product Status	Active
FET Type	N-Channel
Technology	SiCFET (Silicon Carbide)
Drain to Source Voltage (Vdss)	1000 V
Current - Continuous Drain (Id) @ 25°C	22A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	15V
Rds On (Max) @ Id, Vgs	155mOhm @ 15A, 15V
Vgs(th) (Max) @ Id	3.5V @ 3mA
Gate Charge (Qg) (Max) @ Vgs	21.5 nC @ 15 V
Vgs (Max)	±15V
Input Capacitance (Ciss) (Max) @ Vds	350 pF @ 600 V
Power Dissipation (Max)	83W (Tc)
Temperature Range - Operating	-55°C ~ 150°C (TJ)
Mounting Type	Through Hole
Supplier Device Package	TO-247-4L
Package / Case	TO-247-4
Base Product Number	C3M0120100
Standard Package	30 pcs
MSL Level	1 (Unlimited)
ECCN	EAR99
HTSUS	8541.29.0095
California Prop 65	Warning Information
Win Source Part Number	847301-C3M0120100K
Ultra Librarian 3D Model	Ultra Librarian C3M0120100K CAD Model

Alternative Products

Description

The C3M0120100K is a SiCFET (Silicon Carbide) transistor designed for various applications. It is an N-channel FET with a drain to source voltage (Vdss) of 1000 V.

Vdss: 1000 V
Id @ 25°C: 22A
Rds On: 155mOhm @ 15A and 15V
Mounting Type: Through-hole
Package: TO-247-4
Gate Charge (Qg): 21.5 nC @ 15V
Input Capacitance (Ciss): 350 pF @ 600V
Operating Temperature: -55°C to 150°C
Product Status: Active
