MPLEZW-A1-0000-0000E040F

Part No MPLEZW-A1-0000-0000E040F
Manufacturer CreeLED, Inc.
Catalog LED Lighting - White
Description LED EASYWHT NEU WHT 4000K 6SMD
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Optoelectronics - White LED Lighting
Mfr CreeLED, Inc.
Series EasyWhite®, XLamp® MPL-EZW
Package Tape & Reel
Product Status Obsolete
Color White, Neutral
CCT (K) 4000K 4-Step MacAdam Ellipse
Flux @ 85°C, Current - Test 788lm
Flux @ 25°C, Current - Test 1050lm (1000lm ~ 1100lm)
Current - Test 3 x 150mA
Voltage - Forward (Vf) (Typ) 25V
Lumens/Watt @ Current - Test 93 lm/W
CRI (Color Rendering Index) 80
Current - Max 3 x 250mA
Viewing Angle 125°
Mounting Type Surface Mount
Package / Case 6-SMD, No Lead
Supplier Device Package SMD
Size / Dimension 0.518" L x 0.478" W (13.15mm x 12.15mm)
Height - Seated (Max) 0.250" (6.35mm)
Base Product Number MPLEZW
Standard Package 500 pcs
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.41.0000
Win Source Part Number 643849-MPLEZW-A1-0000-0000E040F
Ultra Librarian 3D Model Ultra Librarian MPLEZW-A1-0000-0000E040F CAD Model

Description

The 643849-MPLEZW-A1-0000-0000E040F is a white LED lighting module from CreeLED, Inc.

  • Series: EasyWhite® and XLamp® MPL-EZW
  • Light Color: White, Neutral
  • Package: Tape & Reel
  • Size/Dimension: 0.518" L x 0.478" W (13.15mm x 12.15mm)
  • Seated Height: 0.250" (6.35mm)
  • Standard Package Quantity: 500 pieces
  • Maximum Current: 3 x 250mA
  • Viewing Angle: 125°
  • Forward Voltage: 25V
  • Test Current: 3 x 150mA
  • Correlated Color Temperature (CCT): 4000K
  • MacAdam Ellipse: 4-Step
  • Flux @ 85°C and Test Current: 788lm
  • Flux @ 25°C and Test Current: 1050lm
  • Lumens/Watt: 93 lm/W
  • Color Rendering Index (CRI): 80
  • Mounting Type: Surface Mount
  • Package Description: 6-SMD, No Lead
