RT1463B7 CTS Resistor Products
Same model may have multiple batches, images only for reference.

RT1463B7

Part No RT1463B7
Manufacturer CTS Resistor Products
Catalog Resistor Networks, Arrays
Description RESISTOR NETWORK SMD BGA / DDR SDRAM Terminator RoHS Compliant Parts Available
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer CTS Resistor Products
Packaging Bulk
Part Status Obsolete (End Of Life)
Circuit Type Dual Terminator
Resistance (Ohms) 33
Tolerance ±1%
Number of Resistors 18
Number of Pins 36
Power Per Element 50mW
Temperature Coefficient ±200ppm/°C
Temperature Range - Operating -55°C ~ 125°C
Applications DDR SDRAM
Mounting Style SMD
Manufacturer Package 36-LBGA
Supplier Device Package 36-BGA (9x4)
Dimension 0.354" L x 0.157" W (9.00mm x 4.00mm)
Height - Seated (Maximum) 0.053" (1.34mm)
Manufacturer Pack Quantity 1
MSL Level 1 (Unlimited)
Popularity Medium
Supply and Demand Status Balance
Win Source Part Number 807140-RT1463B7
Ultra Librarian 3D Model Ultra Librarian RT1463B7 CAD Model

Description

The CTS Resistor Products 807140-RT1463B7 is a dual terminator designed for DDR SDRAM applications.

  • Type: SMD
  • Resistance: 33 Ohms
  • Tolerance: ±1%
  • Resistors: 18
  • Pins: 36
  • Power per Element: 50mW
  • Obsolete: Yes
  • Supplier Device Package: 36-BGA (9x4)
  • Temperature Range: -55°C ~ 125°C
  • Dimension: 0.354" L x 0.157" W (9.00mm x 4.00mm)
  • Supply and Demand Status: Balanced
