Same model may have multiple batches, images only for reference.

PEM1-S12-D5-S

Name: PEM1-S12-D5-S
Brand: CUI Inc.
SKU: 1320605
Availability: InStock
Rating: 4.93 (5 reviews)

Get a Quote

Part No	PEM1-S12-D5-S
Manufacturer	CUI Inc.
Catalog	Power Supplies Board Mount DCDC Converters
Description	DC DC CONVERTER +/-5V 1W / Isolated Module DC DC Converter 2 Output 5V -5V 100mA, 100mA 10.8V - 13.2V Input
Datasheet	PEM1-S12-D5-S Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Power Supplies - Board Mount>DC DC Converters
Manufacturer	CUI Inc.
Packaging	Tube
Product Status	Not For New Designs
Type	Isolated Module
Number of Outputs	2
Voltage - Input (Min)	10.8V
Voltage - Input (Max)	13.2V
Voltage - Output 1	5V
Voltage - Output 2	-5V
Current - Output (Max)	100mA, 100mA
Power (Watts)	1 W
Voltage - Isolation	3 kV
Applications	ITE (Commercial)
Features	SCP
Temperature Range - Operating	-40°C ~ 105°C
Efficiency	80%
Mounting	Through Hole
Case / Package	7-SIP Module, 5 Leads
Size / Dimension	0.77" L x 0.24" W x 0.37" H (19.5mm x 6.0mm x 9.3mm)
Approval Agency	EN, UL
Standard Number	55024; 55032 Class A; 60950-1
Base Product Number	PEM1-S12
RoHS Status	RoHS Compliant
MSL Level	1 (Unlimited)
ECCN	EAR99
HTSUS	8504.40.9580
Other Part Number	102-2761,PEM1S12D5S
Standard Package	25
Win Source Part Number	1320605-PEM1-S12-D5-S
Ultra Librarian 3D Model	Ultra Librarian PEM1-S12-D5-S CAD Model

Alternative Products

Description

The CUI Inc. PEM1-S12-D5-S is an isolated module DC-DC converter.

Outputs: two outputs
Maximum Output Current: 100mA each
Input Voltage Range: between 10.8V and 13.2V
Output Voltage (Output 1): 5V
Output Voltage (Output 2): -5V
Power: 1W
Efficiency: 80%
Application: ITE (Commercial) applications
Temperature Range: -40°C to 105°C
Case: 7-SIP module, 5 leads case
Mounting: through hole
Feature: SCP (Short Circuit Protection)
Voltage Isolation: 3 kV
RoHS Compliant: Yes
Approvals: EN and UL
