Same model may have multiple batches, images only for reference.
PDS1-S24-S5-S Real Image
Same model may have multiple batches, images only for reference.

PDS1-S24-S5-S

Part No PDS1-S24-S5-S
Manufacturer CUI Inc.
Catalog Power Supplies Board Mount DCDC Converters
Description DC DC CONVERTER 5V 1W
Datasheet
PDS1-S24-S5-S Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Power Supplies - Board Mount
Estimated Pruduction Lead Time 10 Weeks
Features Isolated Module DC DC Converter Output 5V - - 200mA 21.6V - 26.4V Input
Manufacturer CUI Inc.
Series PDS1-S (1W)
Package Tube
Operating Temperature Range -40°C ~ 105°C (With Derating)
Mounting Through Hole
Package 4-SIP Module
Family Name PDS1-S24
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8504.40.9580
Other Part Number 102-2750, PDS1S24S5S
Quantity per package 43
Popularity High
Supply and Demand Status Balance
Win Source Part Number 930182-PDS1-S24-S5-S
Ultra Librarian 3D Model Ultra Librarian PDS1-S24-S5-S CAD Model

Description

The PDS1-S24-S5-S is a 1W isolated DC/DC converter module manufactured by CUI Inc.

  • Input Voltage Range: 21.6V to 26.4V
  • Output Voltage: 5V
  • Maximum Output Current: 200mA
  • Temperature Range: -40°C to 105°C with derating
  • Mounting: Through-hole
  • Package: 4-SIP module
  • Packaging: Tube
  • Series: PDS1-S (1W)
  • Supply and Demand Status: Balance
  • Quantity per Package: 43
