BTD1760J3 Cystech Electonics Corp.
Same model may have multiple batches, images only for reference.

BTD1760J3

Part No BTD1760J3
Manufacturer Cystech Electonics Corp.
Catalog END - OF - LIFE
Description Low Vcesat NPN Epitaxial Planar Transistor
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

RoHS State Request Verification
Manufacturer Cystech Electonics Corp.
Win Source Part Number 1155463-BTD1760J3
Manufacturer Homepage www.cystekec.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian BTD1760J3 CAD Model

Description

The BTD1760J3 is a NPN transistor from Cystech Electonics Corp.

  • Supply and Demand Status: Balanced.
  • Manufacturer Homepage: www.cystekec.com.
  • Designed for: High voltage and high current applications.
  • Maximum Collector Current: 1A.
  • Maximum Collector-Emitter Voltage: 60V.
  • Current Gain: 200.
  • Saturation Voltage: 0.3V.
  • Ideal for: Applications that require high voltage, high current, and high gain.
