Same model may have multiple batches, images only for reference.

SA01S2409A

Name: SA01S2409A
Brand: Delta Electronics
SKU: 1237500
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	SA01S2409A
Manufacturer	Delta Electronics
Catalog	Power Supplies Board Mount DCDC Converters
Description	DC DC CONVERTER 9V 1W / Isolated Module DC DC Converter 1 Output 9V 110mA 21.6V - 26.4V Input
Datasheet	SA01S2409A Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Power Supplies - Board Mount>DC DC Converters
Mfr	Delta Electronics
Series	SA01S (1W)
Package	Tube
Type	Isolated Module
Number of Outputs	1
Voltage - Input (Min)	21.6V
Voltage - Input (Max)	26.4V
Voltage - Output 1	9V
Current - Output (Max)	110mA
Power (Watts)	1 W
Voltage - Isolation	1 kV
Applications	Medical
Features	SCP
Temperature Range - Operating	-40°C ~ 85°C
Efficiency	77%
Mounting	SMD (SMT)
Package / Case	8-SMD Module
Dimension	0.50" L x 0.42" W x 0.28" H (12.8mm x 10.7mm x 7.0mm)
Base Product Number	SA01S
Other Names	941-1247
Standard Package	10
MSL Level	3 (168 Hours)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8504.40.9580
Win Source Part Number	1237500-SA01S2409A
Ultra Librarian 3D Model	Ultra Librarian SA01S2409A CAD Model

Alternative Products

Description

The Delta Electronics 1237500-SA01S2409A is an isolated module DC-DC converter that has a power output of 1W.

Features: SCP features
Voltage Isolation: 1kV
Component: designed to be used in medical applications
Current Output: 110mA
Efficiency: 77%
Packaged: in an 8-SMD module
Operating Temperature Range: between -40°C to 85°C
