Diodes Incorporated 74AHC1G04W5-7

The 74AHC1G04W5-7 is a high-speed, single-gate CMOS inverter from Diodes Incorporated, designed to deliver optimal performance in a wide range of applications. This inverter is part of the 74AHC family, known for its high-speed operation and compatibility with TTL (Transistor-Transistor Logic) levels. The product is especially suited for use in battery-powered and portable devices due to its low power consumption and compact footprint.

Key Features:

• Logic Type: CMOS Inverter
• Operating Voltage Range: 2.0V to 5.5V, accommodating a variety of logic level requirements and ensuring versatility across different power domains.
• High Speed: Propagation delay time is significantly low, making it suitable for high-speed applications.
• Low Power Consumption: Ideal for battery-operated and power-sensitive applications due to its efficient power usage.
• Output Drive Capability: Capable of driving up to 8 mA at 5V, allowing for direct drive of LEDs and other low-power devices.
• Temperature Range: Operates over a broad temperature range from -40°C to +125°C, ensuring reliability in extreme conditions.
• Mounting Type: Surface Mount, in a compact SOT-25 package, providing a space-saving solution on PCBs.
• RoHS Compliant: Meets environmental standards, making it suitable for use in green and consumer electronics.

Applications:

The 74AHC1G04W5-7 is versatile and can be used in a variety of applications, including:

• Logic level shifting
• Signal inversion
• Oscillator circuits
• Wave shaping and timing circuits
• Portable and battery-powered devices
• Embedded systems

With its robust design and high functionality, the 74AHC1G04W5-7 from Diodes Incorporated is a reliable choice for designers looking to incorporate a high-performance inverter into their electronic circuits.
