The 74LV08AT14-13 is a high-performance, low-voltage Quad 2-Input AND Gate IC from Diodes Incorporated, designed for use in a wide range of electronic applications. This advanced logic gate is part of the 74LV family, which is well-known for its low-power consumption and high-speed operation.

Key Features

• Operating Voltage: The 74LV08AT14-13 operates at a voltage range of 2V to 5.5V, making it suitable for battery-operated devices and low-power applications.
• High-Speed: With a typical propagation delay of only 4.5ns at 5V, this IC ensures fast signal processing, which is crucial for high-speed digital systems.
• Low Power Dissipation: It has a low power consumption, with a maximum ICC of 20µA at 25°C, contributing to energy efficiency in electronic circuits.
• Output Drive Capability: The device can drive up to 8mA at 5V, allowing it to interface with other logic families and drive various loads.
• Logic Level Compatibility: Its inputs are compatible with TTL (Transistor-Transistor Logic) levels, which allows easy integration with existing digital systems.

Applications

The 74LV08AT14-13 is versatile and can be used in a variety of applications, including:

• Logic Function Implementations
• Signal Processing
• Computers and Computer Peripherals
• Control Systems
• Communication Devices

Package and Quality

This IC is available in a TSSOP-14 (Thin Shrink Small Outline Package) form factor, providing a compact solution for space-constrained applications. The 74LV08AT14-13 is also characterized for operation from -40°C to +125°C, ensuring reliable performance across a wide temperature range. Diodes Incorporated is committed to high-quality standards, and this product meets or exceeds industry requirements for performance and reliability.
