Product Overview: 74LVC1G07SE-7 from Diodes Incorporated

The 74LVC1G07SE-7 is a high-performance, single non-inverting buffer with open-drain output, part of the 74LVC family of low-voltage CMOS logic integrated circuits. Manufactured by Diodes Incorporated, this device is designed to operate from a 1.65V to 5.5V power supply, making it suitable for interfacing with both 3.3V and 5V logic levels. This versatility enables the 74LVC1G07SE-7 to be used in a wide range of applications, from consumer electronics to industrial control systems.

Encased in a small SOT-353 package, the 74LVC1G07SE-7 is optimized for minimal space on printed circuit boards, making it an ideal choice for compact and high-density electronic designs. The device features a high fan-out capability, which allows it to drive multiple inputs without degradation of signal quality, and its open-drain output enables it to be used in wired-AND logic configurations.

The 74LVC1G07SE-7 boasts excellent propagation delay characteristics, with a typical propagation delay (tpd) of only 3.7ns at a supply voltage of 3.3V, ensuring fast response times in critical applications. Additionally, the device has a low power consumption, with a typical quiescent current (ICCC) of only 10μA, making it suitable for power-sensitive designs.

This product also features robust ESD protection, which safeguards the device from electrostatic discharge events, enhancing its reliability and longevity in real-world applications. The input is tolerant to 5.5V, even when the device is powered off, providing additional protection and flexibility in mixed-voltage environments.

With its combination of high performance, low power consumption, and compact footprint, the 74LVC1G07SE-7 from Diodes Incorporated is a practical choice for designers looking to implement buffering functions, logic level translation, or open-drain outputs in their digital circuits. Its compliance with the RoHS directive also ensures that it meets current environmental standards, emphasizing Diodes Incorporated's commitment to environmentally responsible manufacturing.
