The AP1118D90L-13 is a high-performance, low-dropout linear regulator offered by Diodes Incorporated, a leading manufacturer in the semiconductor market. This component is designed to deliver a continuous output current of up to 1A, making it an ideal choice for a wide range of applications that require a stable and reliable power supply.

Key Features

• Output Voltage: The AP1118D90L-13 provides a fixed output voltage of 1.8V, which is suitable for powering low-voltage logic devices and microcontrollers.
• High Accuracy: This regulator maintains a high accuracy level, with a low output voltage error, ensuring consistent performance for sensitive electronic circuits.
• Low Dropout Voltage: With a low dropout voltage, the AP1118D90L-13 operates efficiently even when the input voltage is close to the output voltage, reducing power loss and improving overall system efficiency.
• Thermal Protection: The device includes built-in thermal protection to prevent overheating, thus enhancing its reliability and lifespan even under stressful conditions.
• Current Limiting: The current limiting feature protects the regulator and the load from damage due to excessive current draw.
• Wide Operating Temperature Range: It is designed to operate over a wide temperature range, making it suitable for industrial and automotive applications that may experience extreme temperature variations.
• Package: The AP1118D90L-13 comes in a TO-252 (DPAK) package, which is known for its small footprint and ability to handle high levels of power.

Applications

The AP1118D90L-13 is versatile and can be used in a variety of applications, including:

• Consumer Electronics
• Telecommunication Devices
• Computer Peripherals
• Industrial Control Systems
• Battery-Powered Devices

Conclusion

In summary, the AP1118D90L-13 from Diodes Incorporated is a robust and efficient solution for applications requiring a stable 1.8V power supply. With its high accuracy, low dropout voltage, and protective features, it stands out as a reliable choice for designers looking to enhance the performance and safety of their electronic products.
