The AP2151FMG-7 is a high-performance, integrated circuit product developed by Diodes Incorporated, a leading global manufacturer and supplier of high-quality semiconductor products. This device is a single-channel, current-limited integrated high-side power switch optimized for Universal Serial Bus (USB) and other hot-swap applications.

Key Features

• Current Limiting: The AP2151FMG-7 provides precise current limiting to protect the host device from over-current conditions. It is capable of delivering a continuous output current up to 1.5A.
• Fast Response Time: With a quick response time to fault conditions, the device ensures reliable protection for sensitive components.
• Reverse Current Blocking: This feature prevents any backward flow of current from the output to the input, safeguarding the power source and other components in the circuit.
• Over-Temperature Protection: The built-in thermal shutdown function protects the device from damage due to overheating.
• Controlled Rise Time: The AP2151FMG-7 offers a controlled output rise time to reduce inrush current, minimizing the impact on the power source at startup.

Applications

The device is highly versatile and can be used in various applications, including:

• USB Peripherals
• Portable Electronics
• Hot-Swap Supplies
• Battery-Charger Circuits

Quality and Reliability

Diodes Incorporated is committed to providing high-quality products that meet the stringent requirements of the electronics industry. The AP2151FMG-7 is manufactured in compliance with the highest standards to ensure its reliability and performance in critical applications.

Environmental Compliance

The AP2151FMG-7 adheres to environmental standards and is compliant with RoHS directives, making it a suitable choice for eco-conscious applications and manufacturers looking to reduce their environmental impact.

Package and Availability

This product is available in a space-saving 6-pin SOT-26 package, providing a compact solution for designs where board space is at a premium. Check with Diodes Incorporated for availability and bulk ordering options.
