Product Overview: AZ1117CH-ADJTRG1

The AZ1117CH-ADJTRG1 is a high-performance, low-dropout (LDO) linear regulator designed and manufactured by Diodes Incorporated, a leading global provider of discrete, logic, analog, and mixed-signal semiconductors. This regulator is ideal for a variety of applications that require a stable and reliable voltage supply.

Key Features

• Adjustable Output Voltage: The AZ1117CH-ADJTRG1 offers an adjustable output voltage, which can be set from 1.25V to 10.8V using external resistors. This flexibility makes it suitable for a wide range of applications.
• High Efficiency: With a low dropout voltage of typically 1.2V at 800mA of load current, the device ensures efficient operation, reducing power loss and improving overall system performance.
• Current Limiting and Thermal Protection: The regulator includes built-in current limiting and thermal shutdown features, which protect the device and the system from damage due to over-current and overheating conditions.
• Stable with Low ESR Output Capacitors: The AZ1117CH-ADJTRG1 is stable with low equivalent series resistance (ESR) capacitors, making it compatible with a variety of capacitors and ensuring a stable output voltage under different load conditions.
• Package: This LDO regulator is available in a SOT-223 package, which is suitable for surface-mount technology (SMT) and provides a compact footprint for space-constrained applications.

Applications

The AZ1117CH-ADJTRG1 is a versatile component that can be used in a wide range of electronic devices and systems, including:

• Portable and battery-powered equipment
• Microprocessor/microcontroller or logic system power supplies
• Post-regulation for switching supplies
• Consumer electronics such as cameras, DVD players, and TVs
• Telecommunication devices

Quality and Reliability

Diodes Incorporated is committed to providing high-quality products that meet the rigorous standards of the electronics industry. The AZ1117CH-ADJTRG1 is produced with this commitment in mind, ensuring both reliability and performance for critical applications where voltage regulation is paramount.

For detailed specifications, application notes, and additional resources, customers can access the manufacturer's website or contact technical support for further assistance with the AZ1117CH-ADJTRG1 LDO regulator.
