The B1100LB-13-F from Diodes Incorporated is a high-performance Schottky barrier rectifier designed for applications requiring low voltage drop and high efficiency. This rectifier is an ideal choice for power supply designs, offering a combination of low forward voltage drop and high current capability.

Key Features

• Low Forward Voltage Drop: The device features a low forward voltage drop, which enhances the efficiency of the system by reducing power loss during conduction.
• High Current Capability: With a maximum average rectified current of 1A, this rectifier can handle high current applications, making it suitable for a wide range of power supplies and converters.
• High Surge Current Capability: The B1100LB-13-F is capable of withstanding high surge currents, offering robust performance during transient conditions.
• Thermal Performance: The device is encapsulated in a small and thermally efficient SOD-123FL package, providing excellent thermal performance and reliability.
• Lead-Free and RoHS Compliant: This rectifier is environmentally friendly, complying with the RoHS directive and being completely lead-free, making it suitable for use in green products.

Applications

The B1100LB-13-F is suitable for a variety of applications, including:

• DC/DC converters
• Power supply units
• Free-wheeling diodes
• Polarity protection devices
• Low voltage, high frequency inverters
• Energy-efficient applications

Specifications

Parameter Value Average Rectified Current (Io) 1A Peak Repetitive Reverse Voltage (Vrrm) 100V Forward Voltage Drop (Vf) 0.85V @ 1A Operating Temperature Range -65°C to +125°C

In summary, the B1100LB-13-F Schottky barrier rectifier from Diodes Incorporated offers a blend of high efficiency, thermal performance, and surge current capability, making it an excellent choice for modern electronic applications where efficiency and reliability are paramount.
