The B320A-13-F is a high-quality Schottky barrier rectifier designed and manufactured by Diodes Incorporated, a leading company in the semiconductor market. This component is engineered to offer efficient and fast switching with a low forward voltage drop, making it an excellent choice for a wide range of applications including power supply, converter, and high-frequency circuits.

Key Features

• High Current Capability: With a forward continuous current of 3A, the B320A-13-F can handle significant current, making it suitable for high-power applications.
• Low Forward Voltage Drop: The device exhibits a low forward voltage drop, which enhances system efficiency by reducing power loss during operation.
• High Surge Capability: It is capable of withstanding high surge currents, offering robust performance during transient conditions.
• Guard Ring Die Construction: The guard ring design provides enhanced reliability and stability by minimizing the risk of breakdown and leakage currents.
• High-Temperature Operation: The B320A-13-F is designed to operate at junction temperatures as high as 150°C, ensuring reliability in harsh thermal environments.

Electrical Characteristics

The rectifier has a repetitive peak reverse voltage of 20V, and its forward voltage drop is typically 0.71V at 3A, which helps to maintain efficiency in the system. The maximum reverse leakage current is as low as 0.5mA at 20V, contributing to its low standby power consumption.

Package and Mounting

Encased in a SMB (DO-214AA) package, the B320A-13-F is compact and suitable for automated surface-mount processes, thus facilitating high-volume production and integration into various electronic assemblies. Its package is also RoHS compliant, ensuring that it meets current environmental standards regarding hazardous substances.

Applications

The versatility of the B320A-13-F makes it an ideal choice for a variety of applications, including but not limited to:

• Switching power supplies
• Converters
• Free-wheeling diodes
• Reverse battery protection
• DC-DC converters
• Automotive applications

With its combination of high efficiency, thermal stability, and current handling capability, the B320A-13-F from Diodes Incorporated stands out as a robust and reliable component for your power management solutions.
