Product Overview: BAS16TW-7-F

The BAS16TW-7-F from Diodes Incorporated is a high-performance, surface-mount switching diode designed to meet the needs of a wide range of electronic applications. This diode is part of the BAS16 series and comes in a compact SOT-323 package, making it an ideal choice for space-constrained designs.

Key Features

• High-Speed Switching: The BAS16TW-7-F is designed for high-speed switching operations, providing quick response times that are essential for high-frequency circuits.
• Low Forward Voltage Drop: The device features a low forward voltage drop, which enhances its efficiency by minimizing power loss during operation.
• Surface-Mount Package: Its SOT-323 package is optimized for automated assembly processes and helps reduce the overall size of the end product.
• Lead-Free and RoHS Compliant: This diode is lead-free and complies with the RoHS directive, making it suitable for use in environmentally sensitive applications.

Electrical Characteristics

The BAS16TW-7-F has a continuous reverse voltage of 75V and a forward continuous current of 215mA. Its power dissipation is rated at 350mW, and it can handle peak forward surge current up to 2A. The diode's fast switching speed is characterized by its reverse recovery time, which is typically less than 6ns.

Applications

With its high-speed switching capability, the BAS16TW-7-F is widely used in high-frequency applications such as:

• Switching power supplies
• DC-DC converters
• High-speed logic circuits
• Signal processing
• Protection circuits

Quality and Reliability

Diodes Incorporated is known for its commitment to quality, and the BAS16TW-7-F is no exception. It is produced with high manufacturing standards, ensuring reliability and performance consistency. The device's robust construction allows it to operate in a broad temperature range, from -55°C to +150°C, making it suitable for various industrial and commercial environments.

Whether you are designing a sophisticated communication device or a simple power management system, the BAS16TW-7-F offers the performance and reliability you need in a compact, surface-mount package.
