BAS70-05-7-F

Part No BAS70-05-7-F
Manufacturer Diodes Incorporated
Catalog Diodes, Rectifiers - Arrays
Description Rectifier Diode Schottky 70V 0.07A 5ns 3-Pin SOT-23 T/R / DIODE ARRAY SCHOTTKY 70V SOT23-3
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Diodes Incorporated
Packaging Reel - TR
Status Active
Diode Configuration 1 Pair Common Cathode
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 70V
Current - Average Rectified (Io) (per Diode) 70mA (DC)
Voltage - Forward (Vf) (Max) @ If 1V @ 15mA
Reverse Recovery Time (trr) 5ns
Current - Reverse Leakage @ Vr 100nA @ 50V
Operating Temperature - Junction -55°C to 125°C
Mounting SMD (SMT)
Case / Package SOT-23-3
Win Source Part Number 010927-BAS70-05-7-F
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name BAS70-05
Introduction Date August 07, 2000
ECCN EAR99
Country of Origin China, Japan, Taiwan, United Kingdom, United States of America
Halogen Free Compliant
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian BAS70-05-7-F CAD Model

Description

The BAS70-05-7-F is a high-performance Schottky barrier diode designed and manufactured by Diodes Incorporated, a leading global manufacturer and supplier of high-quality semiconductor products. This diode is engineered to offer fast switching capabilities with low forward voltage drop, making it an ideal choice for a variety of applications that require efficient power management and high-speed switching.

Key Features

  • Low Forward Voltage Drop: The device features a low forward voltage drop, which enhances power efficiency and reduces thermal stress on the system.
  • Fast Switching Speed: With its Schottky barrier design, the BAS70-05-7-F provides extremely fast switching speed, which is crucial for high-frequency applications.
  • Surface Mount Package: The diode comes in a compact SOT-23 package, making it suitable for space-constrained applications and easy to integrate into various circuit designs.
  • High Surge Current Capability: It has the ability to handle high surge currents, offering robust performance during transient conditions.
  • Lead-Free and RoHS Compliant: The BAS70-05-7-F is environmentally friendly, complying with the RoHS directive, and is free from lead and other hazardous substances.

Applications

The versatility of the BAS70-05-7-F allows it to be used across a broad range of applications. Some of the typical applications include:

  • High-speed switching circuits
  • Power supply management
  • Protection circuits
  • Voltage clamping
  • Reverse polarity protection

Technical Specifications

Here are some of the key technical specifications of the BAS70-05-7-F:

  • Package: SOT-23
  • Forward Continuous Current: 70 mA
  • Peak Reverse Voltage: 70 V
  • Forward Voltage Drop: 410 mV at 15 mA
  • Operating Temperature Range: -55°C to +125°C

For engineers and designers looking for a reliable and efficient Schottky diode, the BAS70-05-7-F from Diodes Incorporated stands out as a superior choice due to its performance, small form factor, and compliance with environmental standards.
