Product Overview: BC847BVN-7 from Diodes Incorporated

The BC847BVN-7 is a high-quality NPN Bipolar Junction Transistor (BJT) offered by Diodes Incorporated, a leading manufacturer and supplier of high-performance semiconductors. This transistor is part of the BC847 series, which is known for its efficiency and reliability in various electronic applications.

Key Features

• Configuration: The BC847BVN-7 features a dual NPN transistor configuration, which means it contains two independent NPN transistors in a single package. This is ideal for applications where board space is at a premium and where matched transistor pairs are required for circuit stability.
• Package: It comes in a small SOT-563 surface-mount package, which allows for high-density mounting and is suitable for automated assembly processes.
• Power Dissipation: With a power dissipation of 200 mW, this transistor can handle moderate levels of power, making it suitable for a wide range of electronic circuits.
• Collector-Emitter Voltage: It has a collector-emitter voltage (Vceo) of 45V, which provides a good margin for applications operating at lower voltages.
• Collector Current: The maximum collector current (Ic) is 100 mA, which is sufficient for signal processing and small power conversion applications.
• Gain Bandwidth Product: The BC847BVN-7 offers a gain bandwidth product (fT) of 100 MHz, indicative of its capacity to operate effectively at high frequencies.

Applications

The BC847BVN-7 is highly versatile and can be used in a wide array of electronic circuits. Common applications include:

• Switching and amplification in consumer electronics
• Drive circuits in industrial systems
• Signal processing in communication devices
• Audio amplifiers and pre-amplifiers
• Voltage regulation modules
• Digital logic circuits

Quality and Reliability

Diodes Incorporated is committed to providing high-quality products, and the BC847BVN-7 is no exception. It is produced with strict quality control measures and is designed for long-term reliability. This transistor is RoHS compliant, ensuring that it meets the latest environmental standards and is free from hazardous substances.

In summary, the BC847BVN-7 is a compact, efficient, and reliable solution for designers looking to incorporate NPN transistors into their electronic projects. Its dual configuration, high frequency response, and compatibility with automated assembly processes make it an excellent choice for a multitude of applications.
