Introducing the DDTC143ECA-7-F Transistor from Diodes Incorporated

The DDTC143ECA-7-F is a cutting-edge pre-biased (resistor-equipped) transistor, meticulously engineered by Diodes Incorporated, a leading manufacturer in the semiconductor industry. This innovative product is designed to offer a compact, high-performance solution for a variety of electronic applications.

Key Features

• Device Type: Pre-biased Bipolar Transistor (BJT)
• Configuration: Single
• Transistor Polarity: NPN
• Collector-Emitter Voltage VCEO Max: 50V
• Collector-Base Voltage VCBO: 50V
• Emitter-Base Voltage VEBO: 5V
• Collector Current - Continuous IC: 100mA
• Power Dissipation Pd: 150mW
• DC Current Gain (hFE) (Min) @ Ic, Vce: 100 @ 5mA, 5V
• Resistor - Base (R1): 4.7 kOhms
• Resistor - Emitter (R2): Not Applicable
• Mounting Type: Surface Mount
• Package / Case: SOT-23-3
• RoHS: Yes

Product Description

The DDTC143ECA-7-F transistor is an exceptional component that offers the convenience of a built-in biasing resistor, which simplifies circuit design and reduces component count. This NPN transistor is capable of handling a collector-emitter voltage of up to 50V and a collector current of 100mA, making it suitable for switching and amplification applications.

Its power dissipation of 150mW ensures reliable operation even under moderate power conditions. The device boasts a DC current gain (hFE) of 100 at 5mA and 5V, providing stable and predictable amplification characteristics. The inclusion of a 4.7 kOhm resistor for base biasing allows for direct operation from logic signals, or for use as a simple switch.

Encased in a compact SOT-23-3 package, the DDTC143ECA-7-F is designed for surface-mount technology (SMT), offering ease of integration into a broad range of electronic circuits. Its small footprint and low profile make it ideal for space-constrained applications. Furthermore, compliance with RoHS standards ensures that the product meets current environmental regulations, emphasizing Diodes Incorporated's commitment to sustainability.

Whether you're designing consumer electronics, industrial control systems, or automotive applications, the DDTC143ECA-7-F from Diodes Incorporated is a reliable and efficient choice that promises to deliver high performance in a tiny package.
