The DFLS160-7 is a high-performance Schottky diode designed by Diodes Incorporated, renowned for its efficiency and reliability. This diode is part of the PowerDI™ 123 series, which is specifically engineered to provide superior power density and low thermal resistance in a compact package. It is an ideal choice for a variety of applications, including DC-DC converters, freewheeling diodes, reverse battery protection, and OR-ing diodes in high-frequency power supplies.

Key Features:

• Low Forward Voltage Drop: The DFLS160-7 boasts a low forward voltage drop, which enhances system efficiency by minimizing power loss during operation.
• High Current Capability: With a forward continuous current rating of 1A, this diode can handle significant current, making it suitable for high-load applications.
• Low Power Loss: High efficiency is achieved through reduced power loss, which is critical for maintaining the integrity of the device in which it is used.
• High Surge Capacity: The device can withstand high surge currents, ensuring durability and reliability under stress conditions.
• PowerDI™ 123 Package: The innovative package design allows for exceptional thermal performance and a compact footprint on the PCB.

Electrical Characteristics:

The DFLS160-7 has a maximum repetitive peak reverse voltage (V_RRM) of 60V, which makes it suitable for a range of low to medium voltage applications. It also features a low reverse leakage current that ensures minimal power waste when the diode is in the off state.

Applications:

Due to its robust design and electrical efficiency, the DFLS160-7 is versatile and can be used in various electronic circuits. It is particularly suitable for portable devices where power conservation is crucial, as well as in automotive and industrial environments where reliability and performance are paramount.

Environmental and Safety Compliance:

Diodes Incorporated is committed to environmental stewardship. The DFLS160-7 is RoHS compliant, meaning it is free from hazardous substances such as lead, mercury, and cadmium. This compliance ensures that the product is safe for the environment and for use in electronic equipment.
