Product Overview: DMP1096UCB4-7

The DMP1096UCB4-7 is a high-performance, P-Channel enhancement mode MOSFET from Diodes Incorporated, designed to offer efficient power management in a compact form factor. This MOSFET is a suitable choice for a wide range of applications, particularly in portable and battery-powered devices where energy efficiency is paramount.

Key Features

• Low On-Resistance: The device boasts an extremely low on-resistance (R<sub>DS(on)), which translates to reduced conduction losses and improved overall efficiency in applications.
• High Power Dissipation: With a high power dissipation capability, the DMP1096UCB4-7 can handle significant levels of power, making it ideal for more demanding circuits.
• Compact Package: Housed in a small 6-pin U-DFN2020 package, the MOSFET saves valuable board space while still providing excellent thermal performance.
• Gate Protection: Integrated ESD protection guards the gate against electrostatic discharges, ensuring the device's longevity and reliability.

Applications

The versatility of the DMP1096UCB4-7 allows it to be integrated into various applications, including:

• Power Management Circuits
• Load Switches
• Battery Protection
• DC-DC Converters
• Portable Electronic Devices

Technical Specifications

The DMP1096UCB4-7 operates with a drain-source voltage (V<sub>DS) of -12V and a continuous drain current (I<sub>D) of -3.7A. Its threshold voltage (V<sub>GS(th)) is specified at a typical value of -0.45V. The device's maximum R<sub>DS(on) is 70mΩ at V<sub>GS = -4.5V and I<sub>D = -3.7A, showcasing its efficiency in conducting current.

Quality and Reliability

Diodes Incorporated is known for its commitment to quality, and the DMP1096UCB4-7 is no exception. It is manufactured to meet high industry standards, ensuring both performance and durability for the end-user. The product is RoHS compliant, reflecting the company's dedication to environmental responsibility.
