The PI2EQX6804-ANJEX from Diodes Incorporated is a high-performance, low-power, PCIe Gen2 ReDriver designed to enhance signal quality and integrity by performing receive equalization on deteriorated input signal followed by transmit de-emphasis, maximizing system performance. It is an ideal solution for extending PCB traces in motherboard applications, add-in cards, and high-density servers where signal integrity may be compromised due to increased system complexity and operating speeds.

Key Features

• PCIe Gen2 Compliant: This device is fully compliant with PCI Express (PCIe) 2.0 specification, ensuring compatibility with existing architectures and next-generation computer and networking equipment.
• Automatic Equalization: The PI2EQX6804-ANJEX features automatic adaptive equalization, which allows for optimization of signal quality on a per-channel basis to compensate for varying cable lengths and signal losses.
• Low Power Consumption: Designed for energy efficiency, this ReDriver consumes minimal power, making it suitable for power-sensitive applications.
• Adjustable Transmit Output Swing: Users can adjust the transmit output voltage to achieve the best signal integrity for specific applications and trace lengths.
• Hot-Plug Capable: The device can be safely plugged or unplugged from a live PCIe slot, enhancing serviceability and uptime.
• Small Form Factor: The PI2EQX6804-ANJEX comes in a compact package, which is critical for space-constrained applications.

Applications

• Desktop and Laptop PCs
• Server Systems and Data Centers
• High-Performance Computing
• Networking Equipment
• Storage Systems
• Add-in Cards

Overall, the PI2EQX6804-ANJEX is a versatile and reliable solution for systems that require signal integrity improvements without compromising on power consumption or board space. Its advanced features and compliance with PCIe Gen2 standards make it a go-to choice for a wide range of high-speed data transmission applications.
