Diodes Incorporated PI3DPX1203ZHE - High-Performance ReDriver

The PI3DPX1203ZHE from Diodes Incorporated is a state-of-the-art signal ReDriver designed to enhance signal quality across high-speed interfaces. This component is specifically tailored for applications that require improved signal integrity on data paths. As a part of the growing family of ReDrivers from Diodes Incorporated, the PI3DPX1203ZHE is a perfect solution for overcoming signal degradation that can occur due to increased data rates and longer PCB traces.

Key Features

• Interface Support: The device is compatible with a wide range of high-speed interfaces, including USB 3.2 Gen 1, which makes it versatile for use in various applications.
• Adjustable Equalization: It features programmable equalization, allowing for fine-tuning to compensate for different levels of signal loss.
• Flat Gain: The PI3DPX1203ZHE offers flat gain to maintain signal integrity without introducing additional distortion or noise.
• Low Power Consumption: Designed with power efficiency in mind, the ReDriver minimizes power consumption, making it suitable for power-sensitive applications.
• Small Form Factor: The compact size of the PI3DPX1203ZHE allows for easy integration into space-constrained designs.

Applications

The device is ideal for a variety of applications where maintaining signal integrity is crucial. These include:

• Notebook and Desktop Computers
• Docking Stations
• Mobile Devices and Tablets
• Data Storage and Servers
• Networking Equipment

Technical Specifications

The PI3DPX1203ZHE operates over a wide temperature range and comes in a compact 42-contact TQFN package. It features eight differential channels, with each channel supporting a bidirectional data flow. The device is also equipped with built-in power management capabilities, including a low-power standby mode, further reducing the overall system power requirements.

With its combination of performance, power efficiency, and design flexibility, the PI3DPX1203ZHE from Diodes Incorporated is an excellent choice for designers looking to enhance the performance of their high-speed data systems.
