Introducing the PI5USB2546ZHDEX from Diodes Incorporated

The PI5USB2546ZHDEX is a state-of-the-art USB 2.0 high-speed (HS) signal switch with an integrated single-port USB battery charging controller. This innovative product from Diodes Incorporated is designed to meet the needs of modern electronics that require efficient power management and reliable data transfer.

This advanced switch supports the USB 2.0 High-Speed (480 Mbps) standard and is backward compatible with Full-Speed (12 Mbps) and Low-Speed (1.5 Mbps) data rates, ensuring its versatility across various USB interfaces. It is optimized for applications where an upstream port needs to be connected to one of the two downstream ports, making it ideal for a wide range of consumer electronics, including laptops, desktops, docking stations, monitors, and many other USB-enabled devices.

The integrated battery charging controller adheres to the USB Battery Charging Specification Revision 1.2 (BC1.2), allowing for faster charging of portable devices by supplying up to 1.5A to the charging port. This feature is particularly beneficial for users who need to quickly charge smartphones, tablets, and other gadgets that support BC1.2.

Designed with the end-user in mind, the PI5USB2546ZHDEX includes safety features such as over-voltage lockout (OVLO) and over-temperature protection (OTP), which safeguard the device and connected peripherals from potential damage caused by abnormal operating conditions. Additionally, the switch boasts low on-resistance (RON) for the HS signal switches, which minimizes signal distortion and ensures reliable, high-fidelity data transmission.

The PI5USB2546ZHDEX comes in a compact package, making it suitable for space-constrained applications without compromising performance. Its integration of two essential functions—USB switching and battery charging control—into one solution not only simplifies the design process for engineers but also helps reduce the overall bill of materials and save PCB space, making it a cost-effective and efficient choice for modern electronic designs.

With its robust feature set and Diodes Incorporated's commitment to quality, the PI5USB2546ZHDEX is poised to be an essential component in the next generation of USB connectivity and power management solutions.
