Diodes Incorporated SMAJ12A-13-F TVS Diode

Introducing the SMAJ12A-13-F, a robust transient voltage suppressor (TVS) diode from Diodes Incorporated, designed to protect sensitive electronic equipment from voltage transients induced by system inductive load switching and lightning. This high-quality TVS diode is a reliable solution for safeguarding voltage-sensitive components from destruction or degradation. It is ideal for a wide range of applications, including consumer electronics, industrial systems, and communication networks.

The SMAJ12A-13-F is packaged in a low-profile SMA (DO-214AC) package that offers excellent clamping capability, fast response time, and a low incremental surge resistance. With its 12V stand-off voltage, it is specifically tailored to operate in environments where specific voltage levels are paramount. The bi-directional design ensures protection in both polarities when AC signals are present.

Engineered to handle pulses as defined by IEC 61000-4-2 and IEC 61000-4-4, the SMAJ12A-13-F can withstand surge events with ease. The peak pulse power dissipation is rated at an impressive 400W for 10/1000µs waveforms, which is sufficient to handle most transient spikes. Additionally, the device meets the ISO7637-2 & ISO16750-2 surge specifications, making it suitable for automotive load dump protection.

With its operating junction temperature range from -55°C to +150°C, the SMAJ12A-13-F is built to perform reliably in extreme conditions. The TVS diode also features a low leakage current and a glass passivated chip junction, which ensures long-term stability and reliability.

For those concerned with environmental impact, the SMAJ12A-13-F complies with RoHS and is lead-free, minimizing the ecological footprint of your electronic designs. Its matte tin-plated leads provide enhanced solderability and are compatible with high-temperature soldering processes, ensuring a strong and reliable bond to the PCB.

Whether you're designing power supplies, sensitive data lines, or looking to enhance the durability of portable devices, the SMAJ12A-13-F from Diodes Incorporated is a top choice for effective transient voltage suppression.
