FR1M Shanghai Sunrise Electronics
Same model may have multiple batches, images only for reference.

FR1M

Part No FR1M
Manufacturer DIOTEC Electronics Corporation
Catalog Diodes, Rectifiers - Single
Description DIODE FR SMA 1000V 1A
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Rectifiers - Single Diodes
Mfr DIOTEC Electronics Corporation
Package Tape & Reel
Product Status Active
Technology Standard
Voltage - DC Reverse (Vr) (Max) 1000 V
Current - Average Rectified (Io) 1A
Voltage - Forward (Vf) (Max) @ If 1.3 V @ 1 A
Speed Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr) 500 ns
Current - Reverse Leakage @ Vr 5 µA @ 1000 V
Mounting Type Surface Mount
Package / Case DO-214AC, SMA
Supplier Device Package DO-214AC, SMA
Operating Temperature - Junction -50°C ~ 150°C
Standard Package 7,500 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
HTSUS 8541.10.0000
Win Source Part Number 592902-FR1M
Ultra Librarian 3D Model Ultra Librarian FR1M CAD Model

Description

The 592902-FR1M is a fast recovery diode rectifier used in electronic circuits. The 592902-FR1M is part of the DIOTEC Electronics Corporation product line and is currently active in the market.

  • Maximum DC Reverse Voltage: 1000 V
  • Average Rectified Current: 1A
  • Forward Voltage: 1.3 V @ 1 A
  • Reverse Recovery Time: 500 ns
  • Package Type: DO-214AC (SMA)
  • Package: tape and reel
  • Temperature Range: -50°C to 150°C
  • Standard Package: 7,500 pcs
