Z1SMA20-AQ Real Image
Same model may have multiple batches, images only for reference.

Z1SMA20-AQ

Part No Z1SMA20-AQ
Manufacturer DIOTEC Electronics Corporation
Catalog Diodes - Zener - Single
Description ZenerD, 20V, 1W, 5%  /  Zener Diode 20 V 1 W ±5% Surface Mount DO-214AC (SMA)
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products>Diodes - Zener - Single
Mfr Diotec Semiconductor
Series Automotive, AEC-Q101
Package Tape & Reel (TR)
Voltage - Zener (Nom) (Vz) 20 V
Tolerance ±5%
Power - Max 1 W
Impedance (Max) (Zzt) 20 Ohms
Current - Reverse Leakage @ Vr 1 µA @ 15 V
Voltage - Forward (Vf) (Max) @ If 1 V @ 200 mA
Temperature Range - Operating -50°C ~ 150°C (TJ)
Mounting SMD (SMT)
Package / Case DO-214AC, SMA
Supplier Device Package DO-214AC (SMA)
RoHS Status RoHS non-compliant
MSL Level Not Applicable
REACH Status REACH info available upon request
HTSUS 8541.10.0003
Other Names 2721-Z1SMA20-AQTR,2796-Z1SMA20-AQTR
Standard Package 30
Win Source Part Number 1035390-Z1SMA20-AQ
Ultra Librarian 3D Model Ultra Librarian Z1SMA20-AQ CAD Model

Description

The Diotec Semiconductor 1035390-Z1SMA20-AQ is a zener diode designed for use in discrete semiconductor products.

  • Series: automotive AEC-Q101
  • Power Rating: 1W
  • Voltage Tolerance: ±5%
  • Forward Voltage: 1V @ 200mA
  • Reverse Leakage Current: 1μA @ 15V
  • Zener Voltage: 20V
  • Maximum Impedance: 20 ohms
  • Package: DO-214AC (SMA)
  • Operating Temperature: -50°C to 150°C (TJ)
  • RoHS Compliant: No
